Hot Hebei 2 3/8 inch if drill rod

Product details

1 / 1
Number of views:
54

Hot Hebei 2 3/8 inch if drill rod

Hot Hebei 2 3/8 inch if drill rod
Category:
Products
Product number:
308
Key words:
drill rod
Product description
Product Description
OD: 73mm ( 2 7/8'' inch) thread drill pipe
Connection: 105mm
Thread: NC31
Wall thickness: 9.19mm
Length: R1,R2,R3 or as your request
Pipe body material:  High quality alloy seamless pipe of G105
Tool joint material: 35CrMo/ 4137H
Thread treatment: Phosphorization or copper plating
Yield strength: Min 724 Mpa
Tensile strength: Min 793 Mpa
Safe drilling depth: Within 1,800 meters
Suitable: water well, geothermal well, gas well
Strictly according to API 5DP standard
Friction Welded And Thin Buckle Drill pipe:

 1.OCTG selection,rod end upsetting meets API 5D standard.

 2.Thicker tube transfer of heat treatment.

 3.Tool joint fored,controlled atmosphere heat treatment,up to API SPEC-7-1 standard.

 4.Welding area using thermo-mechanical treatment, up to API SPEC-7 standard.

 5.The thread is reverse, apply to salvage tool.

Specification:





OD

2-3/8''

2-7/8''

3-1/2''

4"

5''

Wall Thickness (mm)

7.11

9.19

9.35/11.40

8.38

9.35

Steel Grade

E75 X95 G105 S135 R780

Upset style

IU EU IEU

Hard banding

ARNCO 100XT, ARNCO 300XT, ARMACOR-M, TCS-Ti, TCS-8000

Length

R1:6.1-7.01m; R2:8.84-9.75m; R3:12.19-13.72m

Connection

RSC: NC26, NC31, NC38, NC40, NC46, NC50, etc.

 (NC, XH, IF, REG, FH, etc.)

Customized specifications can be manufactured according to drawings.



1.Drill Pipe steel grade more information:





Steel grade

OD

Internal coating

Hardbanding

Length

E75

X95

R780

G105

S135

2 3/8”~5 1/2”

60.3~139.7mm

TC2000

TC3000

TK34

TK34P

Arnco100XT

Arnco300XT

Armacor-M

TCS-Ti

TCS-8000

R1:6.1-7.01m

R2:8.84-9.75m

R3:12.19-13.72m

2, Drill Pipe steel grade more information:





Steel Grade



                      Yield Strength

         Tensile Strength

min

max

min

Psi

Mpa

Psi

Mpa

Psi

Mpa

E-75

75.000

517

105.000

724

100,000

689

X-95

95.000

655

125.000

862

105,000

724

G-105

105.000

724

135.000

931

115,000

793

S-135

135.000

931

165.000

1138

145,000

1000



3.Drill Pipe Mechanical properties





Specification Yield strength Tensile strength Elongation HB Charpy impact test
Mpa Mpa Mpa A Kv(J)
API SPEC 7 ≥ 827.4 ≥ 965.3 ≥ 13 ≥ 285 ----
SY/T5290-2000 ≥ 827 ≥ 965 ≥ 13 285-341 ≥ 54
HJ-JT 828-1050 1365-1150 ≥ 14 303-341 Vertical horizontal
≥ 87 ≥ 90

Packaging & Shipping:

1. The Geothermal well drilling g105 steel drill pipe will be packed into bundles as 3x3, 3x4, 4x4 etc.and loading into containers after black painting and thread protectors installation.

2. For 20’ container, the max loading weight is 21 metric tons

3. For 40’ container, the max loading weight is 27 metric tons.

4. Usual loading port is XINGANG port in Tianjin, main port in north of China.

Our Services:

1. Drill pipe strictly according to ISO9001 standard

2. If you found to quality problems within one month of the package returned.

3. All strictly according to the contract and fulfill the obligations and responsibilities

4. 24 hours online customer service,feel free contact us.

With quality cast brand, promote the development of integrity!

Main production :

             water well drill pipe

              mining drill pipe

              square drill pipe

              core barrel

              casing pipe

              tool joint

              oil drill pipe

What is the Drill Pipe Application?

1, water well drilling;oil and gas well drilling;geothermal well drilling; geological exploration; mining well drilling; etc.

FAQ

FAQ:

Q: Are you a manufacturer or trading company?

A: We are a specialized manufacturer.

Q: What are your main products, and used for?

A: Our products include core barrel, casing, drill rod, drill rig and other drilling parts.

They are used for mineral exploration, geological drilling.

Q: How about the delivery terms?

A: 1.Payment: T/T, L/C, Western Union, Paypal, 30% deposit in advance and rest before delivery.

     2. Min. order quantity: 1 piece.

     3. Transportation: By sea, train.

Q: How about discount?

A: Price is based on products and order quantity.

Q: Do you accept sample order?

A: Yes sure, please contact us for details.

Q: How about your after-sales service?

A: As a manufacturer has 32 years of history we offer prompt technology support for all problems and questions. Besides, we accept goods return or replace for quality problem.

Q: Where is your factory located in?

A: Our factory is located in SHIJIAZHUANG city, HEBEI province, China.

Q: How does your company control the quality?

A: Quality first. In order to guarantee high quality for our products,  our always make a serious inspection for all products and raw materials in strict procedure. We have obtained certificate of ISO9001.
